AGC UL Inline Mount Fuse Holder Yellow 5061 Waterproof with Accessories
Waterproof FUSE HOLDER with Screw Cap for 3AG 3AB 1/4 X 1-1/4 inch fuses, Panel Mount, Solder Lugs, Rating 10A / 250VAC. Item# 74-FH6. AGC panel mount fuse holder. mit 12-18 ga wire. Made of nylon and bright yellow in color.
Waterproof FUSE HOLDER with Screw Cap for 3AG 3AB 1/4 X 1-1/4 inch fuses, Panel Mount, Solder Lugs, Rating 10A / 250VAC. Item# 74-FH6. AGC panel mount fuse holder. mit 12-18 ga wire. Made of nylon and bright yellow in color.
 3AG AGC Waterproof Inline Fuse Holder Automotive |
 IP67 Inline Mount Fuse Holder Yellow Waterproof In-line Fuse Block UL 94V-0 Rubber |
 Electronics Division BK HHB-R Fuse Holder 30A 32V 1 Circuit Cartridge Free |
| Artikelname: | Waterproof Fuse Holder | Mount-Typ: | Inline, In-line |
| Angewendet auf: | 6×30 Fuses, AGC Fuses | Ur: | 250V |
| Und: | 30A | Körpermaterial: | Thermoplastic Rubber/PVC |
| Körperlänge: | 70mm | Terminalmaterial: | Tinned Brass |
| Cap Type: | Snap In | Fire Retardant Grade: | UL 94V-0 |
| Schutzgrad: | IP67 | Wire Gauge: | 12 14 16 18AWG |
| Wire Length: | Customized | RoHS-konform: | Ja |
| Lnsulation Resistance: | -50°C~185°C | ||
| Hohes Licht: | IP67 Inline Fuse Holders, 70mm Inline Fuse Holders, 30A Yellow Fuse Holder | ||
Produktbeschreibung
IP67 Inline Mount Fuse Holder Yellow Waterproof In-line Fuse Block UL 94V-0 Rubber for 6×30 6×32 Tube FusesProduct Description
For 6x30mm FUSES
Withstanding Voltage:>AC2000V/1min
lnsulation Resistance:≥100mΩ DV500V
Electrical:Rated at 30A 250V AC
Insulating Body: Thermoplastic Rubber/PVC
Terminals:tin plated brass
Operation temperature:-50°C~185°C
| Artikel | Waterproof 6×32 6×30 fuse holder |
| Mouting Style | In-line |
| Max Rating | 30A 250V |
| Body Color | yellow |
| House material | rubber |
| Terminal material | Messing |
| Body length | 70mm |
| Body diameter | 17.6mm |
| Schutzgrad | IP67 |
Features of the Waterproof 6×30 In-line Fuse Holder Yellow Body
Wide range and customized services
| Fuses Amperes | 0.2A~30A (UL lISTED) |
| Wire Gauge | 18AWG 16AWG 14AWG 12AWG (UL1015 PVC) |
| Custom Cable | length & color (upon request) |
This is an in line fuse. Just cut the wire where you want the fuse to go and then slide the wire into the fuse jacket holes on each end and crimp. You’re done. Takes less than a minute to install.
| Structure | body, terminal contacts x2, , wire, fuse |
| Electrical rating | 250V 30A max |
| Körpermaterial | PVC/Rubber |
| Contact Material | Tinned Brass |
| Wire Material | PVC and tinned copper |
AGC UL Inline Mount Fuse Holder Drawing
