BMS Ntc溫度感測器擷取線

用於溫度感測的 NTC 感測器 / 電壓採集 BMS 採集線, Jat 連接器 Mx23A26sf1, Ntc 溫度感測器電纜 UL1332 20AWG 線.

BMS Ntc溫度感測器擷取線

Ntc熱敏電阻動力電池BMS溫度擷取線

Ntc thermistor temperature acquisition line for new energy vehicles

Basic Info.
Model NO: BMS acquisition wiring harness
Bandaging Materials:Corrugated Pipe
General Wiring Harness:Crimping Assembling Classes
Signal:High Voltage Wiring Harness
Shape:Bar
Interface Type:AC/DC
認證:RoHS, ISO9001, CCC
品牌:YAXUN
OEM:Very Welcome
運輸套餐:Inside: PE Bag, Outside: Standard Export Carton
起源:Shenzhen, Guangdong, 中國
海關編碼:8544421100
生產能力:3000000/Year

材料: Shielded high-voltage wire
Use temperature range: -40℃~150℃;
Response speed: 3 秒
Output signal: analog signal output.

產品描述

Model NO.	BMS acquisition wiring harness					application			Shipping terminal, sea/Shipboard power system
Core material	Bare/tinned copper wire conductor					Connector			JAE-26P MX23A26SF1 IRISO-16P IMSA-13065S-2-16A IMSA-13065S-2-12A
Insulation material	FEP / material					working temperature			-40ºC~200ºC
Cable Type	UL1332 20#					額定電壓			DC300V
Cable length	1.2M(Customizable)					Quality Control			100% Inspection Before Shipment
規格
類型	Sectional area	Conductor			Insulation			Conductor resistance		Normal current	Maximum current
		尺寸	Construction	Diameter	厚度		Overall diameter
	mm2	任意波形產生器	No./mm	毫米	毫米		毫米	Ω/KM		A	A
Stranded/UL1332	5.37	10	37/0.43	3.05	0.40		3.71	3.69		20.8	23.7
	3.29	12	19/0.47	2.35	0.40		3.01	5.64		13.1	14.9
	2.04	14	19/0.37	1.85	0.35		2.51	8.96		8.2	9.4
	1.30	16	65/0.160	1.47	0.35		2.13	14.6		5.2	5.9
	0.80	18	41/0.160	1.18	0.30		1.83	23.2		3.2	3.7
	0.50	20	19/0.19	0.95			1.59	36.7		2.0	2.3
	0.30	22	17/0.160	0.76			1.42	59.4		1.28	1.46
	0.20	24	11/0.160	0.61			1.21	94.2		0.81	0.92
	0.10	26	7/0.160	0.49			1.10	150		0.51	0.58
	0.09	28	7/0.127	0.39			0.97	239		0.32	0.36
	0.06	30	7/0.102	0.31			0.90	381		0.2	0.23

Additional information

商標	Ranxuan		10/20PCS per bag with label,export standard carton.
Delivery time	About 1-3 weeks	起源	Shenzhen, 中國
海關編碼	8473409001	throughput	500000 PCS /M

產品優勢:
Shielded high-voltage wire can reduce the impact of EMI (electromagnetic interference) and RFIC radio interference on the vehicle system.

The entire high-voltage wiring harness circuit is shielded to connect the motor, controller and battery and other interfaces. The high-voltage wiring harness shielding layer is connected to the battery motor controller housing through a crimping structure such as a plug-in, and then connected to the body grounding.

The shielding of the high-voltage wire is not necessary for the cable to conduct data, but it can reduce or avoid the radiation of the high-voltage wire.

Product parameters:
Voltage resistance: The rated voltage resistance of conventional automobiles is 600V, and the voltage of commercial vehicles and large buses can be as high as 1000V;
Current resistance: According to the current of the high-voltage system components, it can reach 250~400A;
Temperature resistance: The high temperature resistance level is divided into 125C, 150℃, and 200°C. High temperature conventionally selects 150°C wire, and low temperature conventionally -40°C.

應用領域:
電池管理系統, power battery BMS, new energy vehicles

產品名稱	Wire Harness and Cable Assembly.
規格	Custom Cable&Wire Harness /OEM,ODM.
認證	UL,CSA,CE,VDE,天氣,CCC.
Quality certs	ISO9001,IATF16949, UL factory.
Size Range	Thousands different connectors available.
顏色	According to the requirements of customers.
應用	shipboard/Automotive/Navigation / aviation / shipping terminal / new energy vehicles
Sample	Sample can be provided for evaluating.
QC	Passed ISO9001:2015 Quality control system.All the products are 100% test before delivery.
QC	UL factory certificate of compliance.
起訂量	Sample order/Small order can be accepted.
Delivery Time	Enough stock and strong production capacity ensure timely delivery.
Packaging	50/100/200/300/500/1000PCS per bag with label,export standard carton.
Design ability	We can supply sample,OEM&ODM are welcome (Design,Engineering, Prototype,Sample, Production).
Connector	AMP,TE,莫仕,JAE,Amphenol,Harting,Yonggui,Yazaki,HRS,FCI,日本科學技術協會, or other equivalent.
Connector	Injection waterproof,speicial connector as required.
Emergency Goods	Great freight discount to ship emergency goods by UPS, FedEx, DHL,TNT or air cargo.
